Abrasive belt grinding can process workpieces of various shapes that require high surface quality and precision. Abrasive belt grinding can not only process common plane, inner and outer surface workpieces, but also process large or special-shaped parts with high surface quality and precision requirements with extremely high efficiency. For example: polishing and grinding of large-area plates.
The maximum width of the grinding wheel is only 1000mm, and the abrasive belt can be more than 2500mm. By 2012 the widest known belt grinder used a belt width of 4900mm. In actual use, the common processing width of abrasive belt grinding is 50~2000mm, and the processing thickness is 0.4~150mm. Its productivity is as high as 1000m2/h. This wide abrasive belt grinding can be widely used for steel, stainless steel, silicon steel, aluminum, copper, particleboard, plywood, medium density fiberboard, leather, insulation board, ceramic board, as well as aerospace equipment, ships and nuclear physics research devices Used for surface processing of various high-precision and low-roughness large plates. The precision machining of intermittent planes such as the section of the engine gearbox body can also be formed by grinding with a wide abrasive belt, and it can ensure better sealing than the surface processed by traditional milling and planing.
